SN65HVD230 CAN BusBoard Network Transceiver Module compatible with PCA82C250


Out of stock

SN65HVD230 CAN Board Network Transceiver Evaluation Development Module




The SN65HVD230 CAN Board is an accessory board features an onboard CAN transceiver SN65HVD230,
which is pinout compatible with PCA82C250. It is powered from 3.3V and features ESD protection.
The SN65HVD230 CAN Board is ideal for connecting microcontrollers to the CAN network.

SN65HVD230 can be used under high interference environment.
The device has the ability to send and receive good at different rates.
Fully compatible with ISO11898 standard.
High input impedance, allowing 120 nodes.
Low current standby mode, the typical current of 370μA.
Signal transfer rate up to 1Mb / s.
Thermal protection, open circuit failure protection function.
With anti-instantaneous interference protection bus.
Slope control, reduce radio frequency interference (RFI).
Differential receiver with a wide range of anti-common-mode interference,electromagnetic interference (EMI) capabilities.
PCB Color: May Vary
Size: 38x11x10mm/1.49x0.43x0.39 Inch

Package includes:

1PCS SN65HVD230 CAN Board Network Transceiver Evaluation Development Module
