Microchip PIC16F887-I/P DIP Microcontroller – Brand New UK STOCK UK SELLER

£13.79

3 in stock

Remember this is UK Stock and UK Seller which means Quick Delivery !!

The PIC16F887 from Microchip Technology is a family of low-cost, high-performance, 8-bit, fully static, Flash-based CMOS microcontrollers. It employs a RISC architecture with only 35 single-word/single-cycle instructions. All instructions are single cycle except for program branches which take two cycles. The PIC16F887 delivers performance an order of magnitude higher than its competitors in the same price category. The easy-to-use and easy-to-remember instruction set reduces development time significantly.

The PIC16F887 products are equipped with special features that reduce system cost and power requirements. There are 5 oscillator configurations to choose from, including the high accuracy internal oscillator, power-saving LP (Low Power) oscillator and cost saving RC oscillator. Powersaving Sleep mode, Watchdog Timer and code protection features improve system cost, power and reliability.

High-Performance RISC CPU

  • Only 35 single-word instructions to learn
  • All instructions are single cycle except for program branches which are two-cycle
  • 8-level deep hardware stack
  • Direct, Indirect and Relative Addressing modes for data and instructions
  • Operating speed: up to 20 MHz clock speed, 200 ns instruction cycle time
  • 8K x 14 words of Flash Program Memory
  • 368 x 8 bytes of data memory (RAM)
  • 256 x 8 bytes of EEPROM data memory
  • 35 I/O pins

Special Microcontroller Features:

  • Power-on Reset (POR)
  • Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation
  • Programmable Code Protection
  • Power-Saving Sleep mode
  • In-Circuit Serial Programming™ (ICSP™)
  • Selectable oscillator options:
    • Precision internal oscillator – factory calibrated to within 1%, software selectable range between 8MHz and 31kHz
    • RC: Low-cost RC oscillator
    • XT: Standard crystal/resonator
    • HS: High-speed crystal/resonator
    • LP: Power-saving, low-frequency crystal



Is programming with C confusing? No problem!

We are an authorised reseller of the OshonSoft BASIC programming tools! Take a look at our buyhere22 listing: OshonSoft programming tools.

Please note that we test all our ICs before despatch. Improper handling,misuse or incorrect connection will void warranty

Please read and note the following before ordering:
1) My Shipping is for UK Mainland ONLY. No Scotish Highland, Northern Ireland, Isle of Wight or other Isles. Some areas may incur additional costs, if you are unsure please contact me prior to ordering.
2) Please ensure you have a valid contact phone number, I may pass this number onto the Carrier for delivery. No refund for carriage cost will be offered, if delivery is delayed as a result of no valid contact number being provided.
3) I welcome collection for orders,please select collection on checkout otherwise your order will be despatched. Once your order has been picked and tested if applicable. We will then inform you of a date and time for collection. Please bring your payment card for verification when collecting your order. No order will be released without card verification.
4) I am unable to provide ANY technical support, please ensure you fully understand how this item works by checking for any datasheets (not provided with the item), to enable the product to be used within your application / project.
5) VERY IMPORTANT >> Do not make ANY permanent connections. Please test the item BEFORE making any permanent connections e.g. soldering to the item. Please ensure you have the means to test the item WITHOUT applying ANY solder to the item. If an item has any solder applied I will NOT accept any return.
6) When upgrading to 1st class post, (if the option is available), please note this is sent via Royal Mail and is not a guaranteed next day service. If you need a 48hr service please select 48hr delivery at extra cost. This will be sent via Royal Mail or courier. I do not offer a 24hr service. No weekend or public bank holiday deliveries.
7) We attempt to send out all orders received before 10.00am. This excludes weekends and public holidays.
8) Customers placing multiple orders. – I may ship all the orders as one, please do not ask for a refund of shipping cost after you have placed your orders. Please do not place your orders if you want a refund of shipping cost.
9) Some items may have a “Warranty Void if removed” sticker, please DO NOT tamper or remove these stickers. I will not accept any rertuns with tampered or removed sticker. Some buyers have tried to send back items that I have not supplied.

**** Important note **** Some sellers claim the stock is in the UK, please be careful, the seller is often in China and sends the item to a UK agent who then forwards the item on with a UK stamp. Check where the seller is located not just the item location. All my items are physically with me, here in the UK and I offer a quick delivery and communication within the UK.

During busy periods there maybe a delay in delivering your package by Royal Mail. I apologies in adavnce for any inconvenience but would like to point this out before you place your order.
